Especificaciones generales
Tamaño: 92×92×25mm
Flujo de aire: 37~58 m 3 /h 22-34 CFM
Peso: 268g
Ruido: 28~40dBA
Impulsor: PBT Negro
Marco: aleación de aluminio
Terminales: 0,5 mm
Cable conductor: AWG#22
Motor: Motor de inducción de polo sombreado
Temperatura de funcionamiento: -10°C~+65°C
| Model Number | Bearing Type | Voltage (V) | Freq. (Hz) | Current (A) | Power (W) | Speed (RPM) | Noise (dBA) | Air Flow | Phase | Capacitor | |
| M3/hr | CFM | ||||||||||
| 9225-110BH | Ball | 100~125 | 50/60 | 0.14 | 13 | 2300/2800 | 34/40 | 47/58 | 28/34 | 1 | / |
| 9225-230BH | Ball | 200~240 | 50/60 | 0.07 | 13 | 2300/2800 | 34/40 | 47/58 | 28/34 | 1 | / |
| 9225-110BM | Ball | 100~125 | 50/60 | 0.14 | 13 | 1800/2300 | 28/35 | 37/45 | 22/26 | 1 | / |
| 9225-230BM | Ball | 200~240 | 50/60 | 0.07 | 13 | 1800/2300 | 28/35 | 37/45 | 22/26 | 1 | / |
| 9225-110SH | Ball | 100~125 | 50/60 | 0.14 | 13 | 2300/2800 | 34/40 | 47/58 | 28/34 | 1 | / |
| 9225-230SH | Ball | 200~240 | 50/60 | 0.07 | 13 | 2300/2800 | 34/40 | 47/58 | 28/34 | 1 | / |
| 9225-110SM | Ball | 100~125 | 50/60 | 0.14 | 13 | 1800/2300 | 28/35 | 37/45 | 22/26 | 1 | / |
| 9225-230SM | Ball | 200~240 | 50/60 | 0.07 | 13 | 1800/2300 | 28/35 | 37/45 | 22/26 | 1 | / |
"B" means Ball, "S" means Sleeve, "H" means High Speed, "M" means Middle Speed,
Current, Speed can be customer made
